MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable

MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable

    • MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable
    • MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable
    • MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable
    • MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable
    • MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable

    Product Details:

    Place of Origin: CHINA
    Brand Name: HODCY
    Certification: CE ROHS
    Model Number: HDSMPO

    Payment & Shipping Terms:

    Minimum Order Quantity: 100PCS
    Price: 6.0USD/PCS
    Packaging Details: 1PCS: 26*22*4cm ; 50PCS :65*43*38cm/9.38KGS
    Delivery Time: 3-5 days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 50000 Pieces per Week
    Contact Now
    Detailed Product Description
    Product Name: MTP/MPO Trunk Cable Application: 40G QSFP+ SR Module
    Connector: MPO/MTP Fiber Type: OM3 OM4
    Wavelength: 1260 To 1650nm Cable: 0.9/2.0/3.0 Mm
    Storage Temperature: - 45~+85℃ Return Loss: ≥55dB

    Product Features:

    High Performance in IL & RL

    4,8,12 and 24 fiber connector terminations and assemblies

    Designed for low loss and standard loss SM and MM applications

    Economical solution for mass-termination of fiber

    Suitable for MPO/MTP application

    Ruggedized round cable, oval cable and bare ribbon options available

    Color coded housings available to differentiate fiber type, polish type and/or connector grade

    Compliant to directive 200/95/EC(RoHS)

    MPO connector complies with IEC-61754-7

    Specification:

    MTP/MPO Specifications:

    Type Single Mode Single Mode Multi Mode
    (APC Polish) (UPC Polish) (PC Polish)
    Fiber Count 8,12,24 etc. 8,12,24 etc. 8,12,24 etc.
    Fiber Type G652D,G657A1 etc. G652D,G657A1 etc. OM1,OM2,OM3 etc.
    Maximum Insertion Loss Elite Standard Elite Standard Elite Standard
    Low Loss Low Loss Low Loss
    ≤0.35 dB ≤0.75dB ≤0.35 dB ≤0.75dB ≤0.35 dB ≤0.60dB
    Return Loss ≥60 dB ≥60 dB NA
    Durability ≥500 times ≥500 times ≥500 times
    Operating Temperature -40℃ ~ +80℃ -40℃ ~ +80℃ -40℃ ~ +80℃
    Test Wavelength 1310nm 1310nm 1310nm

    Application

    Data communication network



    Optical System Access network



    Storage area networking fiber channel



    High density architectures



    Note: Maximum Bandwidths of Different Multimode Fibers
    OM1 – 62.5/125um – 10GBit up to 33 meters (108 feet)
    OM2 – 50/125um – 10GBit up to 82 meters (270 feet)
    OM3 – 50/125um, Laser Optimized – 10GBit up to 300 meters (984 feet)
    OM4 – 50/125um, Laser Optimized – 10GBit up to 550 meters (1805 feet)



    MPO(f) to MPO(f) 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable
